PIC16F685-E/ML Datasheet(PDF) 238 Page - Microchip Technology |
|
|
|||||||||||||||||||||||||||||
PIC16F685-E/ML Datasheet(HTML) 238 Page - Microchip Technology |
|
|
238 / 306 page  PIC16F631/677/685/687/689/690 DS41262E-page 236 © 2008 Microchip Technology Inc. 17.3 DC Characteristics: PIC16F631/677/685/687/689/690-E (Extended) DC CHARACTERISTICS Standard Operating Conditions (unless otherwise stated) Operating temperature -40°C ≤ TA ≤ +85°C for industrial -40°C ≤ TA ≤ +125°C for extended Param No. Device Characteristics Min. Typ† Max. Units Conditions VDD Note D020E Power-down Base Current(IPD)(2) —0.05 9 μA 2.0 WDT, BOR, Comparators, VREF and T1OSC disabled —0.15 11 μA3.0 —0.35 15 μA5.0 — 90 500 nA 3.0 -40°C ≤ TA ≤ +25°C D021E — 1.0 17.5 μA 2.0 WDT Current(1) —2.0 19 μA3.0 —3.0 22 μA5.0 D022E — 42 65 μA 3.0 BOR Current(1) — 85 127 μA5.0 D023E — 32 45 μA 2.0 Comparator Current(1), both comparators enabled —60 78 μA3.0 — 120 160 μA5.0 D024E — 30 70 μA2.0 CVREF Current(1) (high range) —45 90 μA3.0 — 75 120 μA5.0 D024AE* — 39 91 μA2.0 CVREF Current(1) (low range) —59 117 μA3.0 — 98 156 μA5.0 D025E — 2.0 18 μA 2.0 T1OSC Current —2.5 21 μA3.0 —3.0 24 μA5.0 D026E — 0.30 12 μA 3.0 A/D Current(1), no conversion in progress —0.36 16 μA5.0 D027E — 90 130 μA 3.0 VP6 Current — 125 170 μA5.0 † Data in “Typ” column is at 5.0V, 25 °C unless otherwise stated. These parameters are for design guidance only and are not tested. Note 1: The test conditions for all IDD measurements in Active Operation mode are: OSC1 = external square wave, from rail-to-rail; all I/O pins tri-stated, pulled to VDD; MCLR = VDD; WDT disabled. 2: The supply current is mainly a function of the operating voltage and frequency. Other factors, such as I/O pin loading and switching rate, oscillator type, internal code execution pattern and temperature, also have an impact on the current consumption. 3: For RC oscillator configurations, current through REXT is not included. The current through the resistor can be extended by the formula IR = VDD/2REXT (mA) with REXT in k Ω. 4: The peripheral current is the sum of the base IDD or IPD and the additional current consumed when this peripheral is enabled. The peripheral Δ current can be determined by subtracting the base IDD or IPD current from this limit. Max values should be used when calculating total current consumption. 5: The power-down current in Sleep mode does not depend on the oscillator type. Power-down current is measured with the part in Sleep mode, with all I/O pins in high-impedance state and tied to VDD. |
|
