MCSO2EL 1/4

v1.0

MCSO2EL

5V Low Frequency CMOS Oscillator

for Extreme Environments

Extreme temperature ranges up to 200°C

High stability & low ageing under extremes

Low current consumption

High shock & vibration resistance

Optional tinned pads (Ag/Cu/Zn)

Option Code

CONFIGURABLE OPTIONS

Parameter

Frequency

32.768kHz

Frequency stability

see note below

Any

±100ppm max over -55 to +125°C

C

±150ppm max over -55 to +150°C

E

±300ppm max over -55 to +175°C

D

±400ppm max over -55 to +200°C

G

Enable / disable function

Any

None (pad 1 NC)

Active (control via pad 1)

E

Terminations

Any

Gold plated pads

Tinned Ag/Cu/Zn

T

*
