ADV3219/ADV3220
Data Sheet
Rev. A | Page 4 of 18
ADV3219
ADV3220
Parameter
Test Conditions/Comments
Min
Typ
Max
Min
Typ
Max
Unit
POWER SUPPLIES
Supply Current
V+, output enabled, no load
7
8
7.5
9
mA
V+, output disabled (EN high)
1.6
2.0
1.8
2.2
mA
V−, output enabled, no load
7
8
7.5
9
mA
V−, output disabled (EN high)
1.6
2.0
1.8
2.2
mA
Supply Voltage Range
±4.5
±5.5
±4.5
±5.5
V
PSR
f = 100 kHz
−72
−69
dB
f = 1 MHz
−62
−60
dB
TEMPERATURE
Operating Temperature Range
Still air
−40
+85
−40
+85
°C
Operating Junction-to-Ambient
Thermal Impedance, θJA
Still air
85
85
°C/W
Table 2. Logic Levels
VIH
VIL
IIH
IIL
SELECT, EN
SELECT, EN
SELECT, EN
SELECT, EN
+2.0 V minimum
+0.8 V maximum
±2 μA maximum
±2 μA maximum
