UL22

Preliminary

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

10 of 13

www.unisonic.com.tw

QW-R125-088.a



REFERENCE DESIGN

4.5W, 2-channel COLOR control by ON/OFF AC-Switch (Free-Dimming

TM)

Featured

Device

Application

Input Voltage

Output Voltage

(Rated Current)

Rated Output

Power

Topology

UTC UL22

LED Driver with

Free-Dimming

90~264VAC

30V/150mA

4.5W

Flyback with

DCM fixed FOSC

Schematic

Figure 4: Schematic

Typical Performance

Table 1: Measured Results

Vin

90Vac

110Vac

135Vac

175Vac

220Vac

264Vac

Pin, [W]

5.644

5.585

5.584

5.629

5.691

5.797

VLED, [V]

32.20

31.93

31.91

31.90

ILED, [mA]

149.3

149.2

149.3

149.4

EFFLED, [%]

85.18

85.3

85.31

84.58

83.69

82.21

ACC, [%]

0.00

-0.07

0.00

0.07

THD, [%]

8.389

7.122

9.859

10.328

15.356

19.949

0.993

0.99

0.983

0.967

0.939

0.907
