BAS70DW, BAS70ADW, BAS70CDW, BAS70SDW

BAS70DW, BAS70ADW, BAS70CDW, BAS70SDW

SMD Small Signal Diode Arrays

SMD Kleinsignal-Dioden-Arrays

Version 2018-09-19

SOT-363

Dimensions - Maße [mm]

Typical Applications

Signal processing, High-speed

switching, Polarity protection

Commercial grade

Suffix -AQ: in AEC-Q101 qualification 1)

Typische Anwendungen

Signalverarbeitung, Schnelles

Schalten, Verpolschutz

Standardausführung

Features

Compliant to RoHS, REACH,

Besonderheiten

Konform zu RoHS, REACH,

Taped and reeled

3000 / 7“

Gegurtet auf Rolle

Weight approx.

0.01 g

Gewicht ca.

Case material

UL 94V-0

Gehäusematerial

Solder & assembly conditions

260°C/10s

Löt- und Einbaubedingungen

MSL = 1

3

Single

Diodes

BAS70DW

1 = A1, 2 = A2, 3 = A3

4 = C3, 5 = C2, 6 = C1

Type

Code

7A

2 x 2

Common

Anode

BAS70ADW

1 = C1, 2 = C2, 3 = A3/A4

4 = C3, 5 = C4, 6 = A1/A2

Type

Code

7B

2 x 2

Common

Cathode

BAS70CDW

1 = A1, 2 = A2, 3 = C3/C4

4 = A3, 5 = A4, 6 = C1/C2

Type

Code

7C

4 in

Bridge

Config-

uration

BAS70SDW

1 = A1, 2 = C2, 3 = A4/C3

4 = A3, 5 = C4, 6 = A2/C1

Type

Code

7D

Maximum ratings 2)

Total power dissipation (per package) − Gesamtverlustleistung (pro Gehäuse)

200 mW 3)

Max. average forward current – Dauergrenzstrom

DC

Non repetitive peak forward surge current – Stoßstrom-Grenzwert

100 mA

Repetitive peak reverse voltage – Periodische Spitzensperrspannung

70 V

Reverse voltage – Sperrspannung

DC

70 V

Junction temperature – Sperrschichttemperatur

Storage temperature – Lagerungstemperatur

-55…+125°C

-55…+125°C

1

Please note the detailed information on our website or at the beginning of the data book

Bitte beachten Sie die detaillierten Hinweise auf unserer Internetseite bzw. am Anfang des Datenbuches

2

3

© Diotec Semiconductor AG

http://www.diotec.com/

1

Pb

RoHS

2.4

2 x 0.65

5

6

4

2

±0.1

Type

Code

3

2

1

5

6

4

2

1

3

5

2

1

3

6

4

5

2

1

3

6

4

5

2

1

3

6

4
