AC-DC Power Supplies
1 of 1
Creation Date : February 15, 2019 (GMT)
JWT75-522/R
Sales Region
Worldwide
Series
JWT
Status
Production
Feature
Option
Remote ON/OFF control
Option Lineup
Please refer to here.
Recommended EMC Filter Please refer to here.
Accessories
Please refer to the catalog
Electrical Characteristics
Input Voltage Range[AC]
85 to 265V
Input Voltage Range[DC]
120 to 330V
Efficiency
72% Typ.
Rated Output Voltage[DC]
+5V +12V -12V
Output Voltage Range[DC]
+5 to
+5.25V
Fixed
Fixed
Minimum Output Current
0.8A 0A
0A
Maximum Output Current
8A
4A
0.5A
Maximum Average Current
Maximum Peak Current
Total Maximum(Average) Output Power
75W
Total Maximum Peak Power
Cases Shape & Size
Case’ｓ shape
Unit
Width(W)
42mm Nom.
Height(H)
92mm Nom.
Depth(D)
188mm Nom.
Weight
600g Typ.
Other
Operating Temp. Range
-10 to 65°C
Cooling
Convection cooling
Safety Standard(Certified)
UL60950-1
CSA C22.2 No.60950-1
EN60950-1
Safety Standard(Conformed)
Den-an
