Technical Data
10408
Effective June 2015
FP1008R1 and FP1008R2
High frequency, high current power inductors
www.eaton.com/elx
0
10
20
30
40
50
60
0.00.2
0.40.6
0.81.0
1.21.4
1.6
FP1008R1
0
10
20
30
40
50
60
0.00.2
0.40.6
0.81.0
1.21.4
1.6
FP1008R2
1.75
4.0
2.0
1.5 dia
1.5 dia
16.0
8.2
11.5
11.0
8.3
24
±0.3
User direction of feed
FP1008Rx
Rxxx
wwllyy R
Total Loss (W)
Total Loss (W)
Packaging information (mm)
Temperature rise vs. total loss
Supplied in tape and reel packaging, 500 parts per 13” diameter reel.
