1 / 4 page  Technical Data 4355 Effective June 2017 Supersedes March 2012 Product features • 13.4 x 12.7 x 8.0mm surface mount package • Ferrite core material • High current carrying capacity, Low core losses • Controlled DCR tolerance for sensing circuits • Inductance range from 110nH to 440nH • Current range from 37 to 120 Amps • Frequency range up to 2MHz Applications • Storage temperature range (component): -40 °C to +125 °C • Operating temperature range: -40 °C to +125 °C (ambient plus self-temperature rise) • Solder reflow temperature: J-STD-020 (latest revision) compliant FP1308R High frequency, high current power inductors Pb HALOGEN HF FREE • Multi-phase regulators • Voltage Regulator Module (VRM) • Desktop and server VRMs and EVRDs • Data networking and storage systems • Graphics cards and battery power systems • Point-of-load modules • DCR sensing Environmental data SMD Device |
