Technical Data 4114
Effective October 2015
Supersedes March 2007
Product description
•
Compact footprint
•
Designed for high density, high current/low
voltage applications
•
Foil technology that adds higher reliability factor
over the traditional magnet wire used for higher
frequency circuit designs
•
Frequency Range up to 1MHz
•
Ferrite core material
Applications
•
Distributed power systems DC-DC converters
•
General-purpose low voltage supplies
•
Computer systems
•
Servers
•
Point of Load (POL) converters
•
Industrial Equipment
•
Networking/Telecom power supplies
Environmental data
•
Storage temperature range (component):
-40°C to +125°C
•
Operating temperature range: -40°C to +125°C
(ambient + self-temperature rise).
•
Solder reflow temperature: J-STD-020D
compliant.
HC2LP
Low profile, high current power inductors
Pb
HALOGEN
HF
FREE
