© 2019 Kingbright. All Rights Reserved. Spec No: DSAH9432 / 1203001856 Rev No: V.9B Date: 03/22/2019

Page 2 / 4

APT2012QWF/D

Parameter

Symbol

Emitting Color

Value

Unit

Typ.

Max.

Chromaticity Coordinates x

x

[1]

White

0.31

-

-

Chromaticity Coordinates y

y

[1]

White

0.31

-

-

Capacitance

C

White

100

-

pF

[2]

White

3.3

4.0

V

White

-

50

µA

Parameter

Symbol

Value

Unit

Power Dissipation

120

mW

Reverse Voltage

5

V

Junction Temperature

115

°C

Operating Temperature

-40 to +85

°C

Storage Temperature

-40 to +85

°C

DC Forward Current

30

mA

Peak Forward Current

[1]

150

mA

Electrostatic Discharge Threshold (HBM)

-

250

V

Notes:

1. Measurement tolerance of the chromaticity coordinates is ±0.01.

2. Forward voltage: ±0.1V.

3. Excess driving current and / or operating temperature higher than recommended conditions may result in severe light degradation or premature failure.

Notes:

1. 1/10 Duty Cycle, 0.1ms Pulse Width.

2. Relative humidity levels maintained between 40% and 60% in production area are recommended to avoid the build-up of static electricity – Ref JEDEC/JESD625-A and JEDEC/J-STD-033.
