AS04004PR-R

40mm Speaker

Product Overview

• 40mm diameter speaker with Neodymium magnet for 86 dB sensi vity

• 3W con nuous, 4W maximum power handling and 4Ω impedance

• Rubber surround and treated paper cone for weather resistance

Frequency Response (1W @ 0.5 meters) and Impedance Graph

3541 Stop Eight Road • Dayton, Ohio 45414
