Data Sheet

AS08308CR-R

More than ever before, high quality audio is the determining factor that

distinguishes your product from the fray. When the sound quality of your

product is on the line, choose High Fidelity speakers from PUI Audio.

The eight ohm 83mm AS08308CR-R speaker is designed for high fidelity audio

reproduction, high power handling, and features a magnetically shielded motor

to prevent stray magnetic fields—focusing the BL product on the voice coil.

Features:

•

Woven glass-fiber cone and rubber surround for weather resistance

•

15W max power handling

•

High-energy shielded motor design for maximum sensitivity

•

Capable of over 94 dB of output at 1 meter

•

Ultra-wide frequency response

Specifications

Parameters

Values

Units

Rated Input Power

7

Watts

Max Input Power

15

Watts

Impedance

8 ± 15%

Ohms

Sensitivity (SPL @ 1W/1m)

Average 0.5, 1.0, 2.0, 4.0 kHz

82 ± 3

dB

Resonant Frequency

109 ± 20%

Hz

Frequency Range (-10 dB)

70 ~ 20,000

Hz

Frame Material

Steel

-

Magnet Material

Dual Ferrite

-

Weight

280

Grams
