SWF1608LF-R68K Datasheet(PDF) 1 Page - TAI-TECH Advanced Electronics Co., Ltd. |
|
|
|||||||||||||||||||||||||||||
SWF1608LF-R68K Datasheet(HTML) 1 Page - TAI-TECH Advanced Electronics Co., Ltd. |
|
|
1 / 2 page  TAI-TECH www.tai-tech.com.tw P2 1. Features 2. Dimensions 3. Part Numbering 4. Specification TAI-TECH Part Number Inductance (uH) Tolerance Test Frequency (Hz) Q Typ Test Frequency (MHz) SRF (MHz) typ. DCR (Ω) max. IDC (mA) max. SWF1608LF-47N□ 0.047 K 0.5V/7.9M 17 7.9 1700 0.075 1500 SWF1608LF-72N□ 0.072 K 0.5V/7.9M 17 7.9 1700 0.12 1500 SWF1608LF-R10□ 0.1 K 0.5V/7.9M 17 7.9 1500 0.12 1500 SWF1608LF-R15□ 0.15 K 0.5V/7.9M 17 7.9 1350 0.15 1450 SWF1608LF-R18□ 0.18 K 0.5V/7.9M 17 7.9 1150 0.15 1400 SWF1608LF-R33□ 0.33 K 0.5V/7.9M 17 7.9 850 0.46 900 SWF1608LF-R39□ 0.39 K 0.5V/7.9M 17 7.9 810 0.51 1100 SWF1608LF-R47□ 0.47 K 0.5V/7.9M 17 7.9 720 0.62 1050 SWF1608LF-R56□ 0.56 K 0.5V/7.9M 17 7.9 600 0.44 850 SWF1608LF-R68□ 0.68 K 0.5V/7.9M 17 7.9 600 0.52 850 SWF1608LF-R82□ 0.82 K 0.5V/7.9M 17 7.9 480 0.69 750 SWF1608LF-R91□ 0.91 K 0.5V/7.9M 17 7.9 330 0.76 670 SWF1608LF-1R0□ 1.00 K 0.5V/7.9M 17 7.9 310 0.81 600 1. Ferrite core wire wound construction. 2. High Reliability due to wire wound type construction. 3. Small footprint as well as low profile. 4. Application for Signal Use. 5. 100% Lead(Pb) & Halogen-Free and RoHS compliant. 6. Operating temperature-40~+125℃ (Including self - temperature rise) SWF 1608 L F - R10 K A B C D E F A: Series B: Dimension L x W C: Application For Signal Use D: Lead free type E: Inductance R10=0.1uH F: Inductance Tolerance J=±5%,K=±10% Size A B C D E SWF1608 1.65±0.15 1.15±0.15 1.05±0.15 ±0.15 0.38 ref. 0.35±0.1 Unit:mm Winding Type Chip Inductor SWF1608LF-SERIES Halogen-free Halogen |
