TAI-TECH

P3

5. Specification

Part Number

Inductance

L0 (uH)±20%

I rms ( A )

Typ

I sat ( A )

Typ

DCR(mΩ)

Typ.@25℃

DCR(mΩ)

Max.@25℃

TMPC0503H-R10YG-D

0.10±30%

23.0

27.0

2.5

3.0

TMPC0503H-R20YG-D

0.20±30%

16.0

25.0

2.6

3.2

TMPC0503H-R22MG-D

0.22

15.5

21.0

3.7

4.4

TMPC0503H-R33MG-D

0.33

14.0

18.0

4.3

5.0

TMPC0503H-R47MG-D

0.47

12.0

16.0

6.4

7.4

TMPC0503H-R68MG-D

0.68

8.50

14.0

10

12

TMPC0503H-1R0MG-D

1.00

7.00

11.0

13

14

TMPC0503H-1R2MG-D

1.20

6.50

11.0

14

16

TMPC0503H-1R5MG-D

1.50

6.00

10.0

16

25

TMPC0503H-2R2MG-D

2.20

5.50

9.00

25

35

TMPC0503H-3R3MG-D

3.30

5.00

8.00

32

38

TMPC0503H-3R6MG-D

3.60

4.90

7.00

46

54

TMPC0503H-4R7MG-D

4.70

4.60

6.00

50

53

TMPC0503H-5R6MG-D

5.60

4.25

4.50

55

63

TMPC0503H-6R8MG-D

6.80

4.00

4.30

68

76.2

TMPC0503H-100MG-D

10.0

2.75

3.50

110

128

TMPC0503H-150MG-D

15.0

2.10

2.60

165

190

TMPC0503H-180MG-D

18.0

2.00

2.30

195

230

TMPC0503H-220MG-D

22.0

1.90

1.70

220

250

TMPC0503H-330MG-D

33.0

1.60

1.60

380

440

Note:

2. All test data referenced to 25℃ ambient.

3. Testing Instrument(or equ) : L: HP4284A,CH11025,CH3302,CH1320,CH1320S LCR METER / Rdc:CH16502,Agilent33420A MICRO OHMMETER.

4. Heat Rated Current (Irms) will cause the coil temperature rise approximately ΔT of 40℃

6. The part temperature (ambient + temp rise) should not exceed 125℃under worst case operating conditions.Circuit design,component,PCB trace size and

thickness,airflow and other cooling provisions all affect the part temperature. Part temperature should be verified in the end application.

7. Special inquiries besides the above common used types can be met on your requirement.
