Digital Controller
E5AK/E5EK
Meaning
Motor calibration has ended with an error.
Action
First, correctly connect the wiring for the potentiometer, open output, and close output.
Execute the motor calibration again.
Operation Procedure
Operation at Error
When motor calibration is executed, open output will operate and then close output will operate. However, as the
value is incorrect, the result turns out to be an error.
Motor Calibration Error (Displayed on the No. 2 Display)
