background image
TP10DA SERIES
www.gztoppower.com
TEL:0086-20-62162688
Email:sales2@gztoppower.com
page2 /3
DERATING CURVE
MECHANICAL DIMENSIONS
PIN DESIGN
DIP package
RECOMMENDED FOOTPRINT DETAILS
TUBE OUTLINE DIMENSIONS
MODEL SELECTION
TP 10
D
A
24
D 12
W
W:4:1 Wide voltage input range
Output voltage
S:single output
D:Dual output
Input Rated Voltage
Package type
DC-DC
Output rated power
Brand name
Pin standard:
φ 0.6mm
Grid spacing: 2.54mm (0.1inch)
TOPPOWER
