Features & Benefits

•

Developed according to ISO 26262, compliant with the requirements of ASIL B(D)

•

Low jitter 0.02% due to high switching accuracy enables iTPMS

•

Two-wire current interface 7mA/14mA providing speed information

•

Wide operating junction temperature range -40°C to 190°C

•

Robustness against external magnetic disturbances up to 2mT through differential sensing principle

•

High sensitivity enables outstanding air gap performance along with immunity against y-displacement

effects

•

Small sensor package 5x3mm without need of external capacitor saves module size, increases robustness

against mechanical stress, and enables design freedom

•

Advanced EMC concept maximizes the availability of the sensor signal

•

New established Micro Break feature designed to be immune against disturbances on supply line

Order Information

Table 1

Type

Description

Ordering

Number

TLE5045iC-R050

50 Ω

SP001649080

TLE5045iC-R100

Speed only sensor optimized for use with load resistor 50 Ω ≤

SP001216864

TLE5045iC

Technical product description

About this product

Technical Product Description

2

Revision 1.0

2018-11-06
