MODEL: ABS3

ABS3 SPECIFICATIONS

ES-9413 Rev.4 Page 4/4

https://www.m-system.co.jp/

PANEL CUTOUT unit: mm (inch)

• Single Mounting

(Conform to degree of protection IP66)

• Clustered Mounting

(Not conform to degree of protection IP66)

+0.5

n × 48 – 3

+0.5

n : number of the units

Panel thickness : 1 to 8 mm

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

OUTPUT

–

U (+)

V (−)

POWER

Output

Driver

Voltage

Input

Current

Input

–

Display /

Setting

A / D

Converter

Isolation
