MODEL: M3LR

M3LR SPECIFICATIONS

ES-2662 Rev.13 Page 3/4

http://www.m-system.co.jp/

EXTERNAL VIEW

Configuration DIP SW

4

5

6

■ FRONT VIEW

■ SIDE VIEW

8

SW2

SW1

SW3

7 6 5 4 3 2 1

ON

OFF

ON

OFF

4 3 2 1

ON

OFF

4 3 2 1

10 11 12

7

8

9

Configurator Jack

DOWN Button

UP Button

MODE Button

LED3 (LD3)

LED2 (LD2)

LED1 (LD1)

The DIP switch setting is required to select output types before setting a precise output range using the PC configurator

software.

For detailed information on the configuration and calibration, refer to the instruction manual.

INPUT TYPE, RANGE & ACCURACY

■ INPUT TYPE, RANGE & ACCURACY

TABLE 8

RTD

°C

°F

MIN.SPAN

MAXIMUM RANGE

MIN.SPAN

MAXIMUM RANGE

Pt 100 (JIS ’97, IEC)

Pt 200

Pt 300

20

20

20

-200 to +850

-200 to +850

-200 to +850

±0.15

±0.15

±0.15

36

36

36

-328 to +1562

-328 to +1562

-328 to +1562

±0.27

±0.27

±0.27

Pt 400

Pt 500

Pt 1000

20

20

20

-200 to +850

-200 to +850

-200 to +850

±0.15

±0.15

±0.15

36

36

36

-328 to +1562

-328 to +1562

-328 to +1562

±0.27

±0.27

±0.27

Pt 50Ω (JIS ’81)

JPt 100 (JIS ’89)

Ni 100

20

20

20

-200 to +649

-200 to +510

-80 to +260

±0.15

±0.15

±0.15

36

36

36

-328 to +1200

-328 to +950

-112 to +500

±0.27

±0.27

±0.27

Ni 120

Ni 508.4Ω

Ni-Fe 604

Cu 10 @25°C

20

20

20

20

-80 to +260

-50 to +200

-200 to +200

-50 to +250

±0.15

±0.15

±0.15

±0.50

36

36

36

36

-112 to +500

-58 to +392

-328 to +392

-58 to +482

±0.27

±0.27

±0.27

±0.90

*1. Or ±0.1% of span, whichever is greater.

If the selected output span equals to or narrower than the one-tenth of the maximum span, add 0.2%.
