1 / 11 page  series Low Power Voltage Detector Ver1.1 1 Oct 3,2011 Features Low power consumption Low temperature coefficient Built-in hysteresis characteristic High input voltage (up to 12V) Output voltage accuracy: tolerance ±1% or ±2% TO92, SOT89 and SOT23 package Applications Battery checkers Level selectors Power failure detectors Microcomputer reset Battery memory backup Non-volatile RAM signal storage protectors General Description The series devices area set of three terminal low power voltage detectors implemented in CMOS technology. Each voltage detector in the series detects a particular fixed voltage ranging from 0.9V to 5.0V. The voltage detectors consist of a high-precision and low power consumption standard voltage source as well as a comparator, hysteresis circuit, and an output driver (CMOS inverter or NMOS open drain). CMOS technology ensures low power consumption. Although designed primarily as fixed voltage detectors, these devices can be used with external components to detect user specified threshold voltages. Selection Table Part No. Det. Voltage Hys. Width Output Tolerance Package HM70C09XX 0.9V 4% CMOS ±2% TO92 SOT89 SOT23-3 SOT23-5 HM7009XX 0.9V 4% NMOS ±2% 1.0V 4% CMOS 1.0V 4% NMOS 1.1V 4% CMOS 1.1V 4% NMOS 1.2V 4% CMOS 1.2V 4% NMOS … … 4% … 5.0V 4% CMOS 5.0V 4% NMOS Order Information ①②③④⑤ DESIGNATOR DESCRIPTION DESIGNATOR DESCRIPTION ① Output Configuration: C=CMOS =N-ch open drain Package Type: M=SOT23-3 P=SOT89 N=SOT25 T=TO-92(Standard) L=TO-92(Custom pin configuration ②③ Detect Voltage 25=2.5V 38=3.8V Device Orientation: R=Embossed Taped(Right) L=Embossed Taped(Left) H=Paper Type(TO-92) B=Bag(TO-92) HM70 HM70 Shenzhen H&M Semiconductor Co.Ltd http：//www.hmsemi.com HM70C10XX HM7010XX HM70C11XX HM7011XX HM7012XX HM70C12XX HM7050XX HM70C50XX ±2% ±2% ±2% ±2% ±2% ±2% ±2% ±2% ±2% ④ ⑤ (space) |
