TSB712AIYST Datasheet(PDF) 1 Page - STMicroelectronics |
|
|
|||||||||||||||||||||||||||||
TSB712AIYST Datasheet(HTML) 1 Page - STMicroelectronics |
|
|
1 / 36 page  MiniSO8 TSB712 and TSB712A TSB714 and TSB714A TSB711 and TSB711A SO8 SOT23-5 SO14 TSSOP14 Features • Rail-to-rail input and output • Low offset voltage: 300 µV maximum • Wide supply voltage range: 2.7 V to 36 V • Gain bandwidth product: 6 MHz • Slew rate : 3 V/µs • Low noise : 12 nV/√Hz • Integrated EMI filter • 2 kV HBM ESD tolerance • Extended temperature range : -40 °C to +125 °C • Automotive-grade available Applications • High-side and low-side current sensing • Hall effect sensors • Data acquisition and instrumentation • Test and measurement equipments • Motor control • Industrial process control • Strain gauge Description The TSB711, TSB711A, TSB712, TSB712A,TSB714 and TSB714A 6 MHz bandwidth amplifiers feature rail-to-rail input and output, which is guaranteed to operate from +2.7 V to +36 V single supply as well as from ±1.35 V to ±18 V dual supplies. These amplifiers have the advantage of offering a large span of supply voltage and an excellent input offset voltage of 300 µV maximum at 25 °C. The combination of wide bandwidth, slew rate, low noise, rail-to-rail capability and precision makes the TSB711, TSB711A, TSB712, TSB712A,TSB714 and TSB714A useful in a wide variety of applications such as: filters, power supply and motor control, actuator driving, hall effect sensors and resistive transducers. Maturity status link TSB711, TSB711A, TSB712, TSB712A, TSB714, TSB714A Related products TSB571, TSB572 Single, Dual op-amps for the low-power consumption version (380 µA with 2.5 MHz GBP) Precision rail-to-rail input / output 36 V, 6 MHz op-amps TSB711, TSB711A, TSB712 TSB712A, TSB714, TSB714A Datasheet DS12487 - Rev 6 - October 2020 For further information contact your local STMicroelectronics sales office. www.st.com |
