MODEL: R3-MEX2

R3-MEX2 SPECIFICATIONS

ES-8279 Rev.2 Page 2/4

https://www.m-system.co.jp/

OUTPUT SPECIFICATIONS

■ Control Output: SSR (zero-crossing); 20 - 240 V AC 0.1 -

1 A

Leakage current at OFF: Approx. 10 mA @ 240 V AC

Output operation at loss of communication: When a

communication error occurs in the middle of an output

operation, the operation continues toward until reaching

target position most recently set by Host device.

Deviation

+

–

0

Deadband

▼

Output Operation: (terminal No. in parentheses)

(2 – 11) ON to min.

(1 – 11) ON to max.

Deviation

+

–

0

Deadband

▼

(7 – 16) ON to min.

(6 – 16) ON to max.

INSTALLATION

Operating temperature: -10 to +55°C (14 to 131°F)

Operating humidity: 30 to 90 %RH (non-condensing)

Atmosphere: No corrosive gas or heavy dust

Mounting: Installation Base (model: R3-BSx)

Weight: 190 g (0.42 lb)

PERFORMANCE

■ POSITION FEEDBACK INPUT

Conversion accuracy: ±0.4 %

The conversion accuracy is defined against the

potentiometer's full span.

Conversion rate: 10 msec.

Data range: 0 – 1000

Data allocation: 4

Current consumption: Approx. 50 mA

Temp. coefficient: ±0.015 %/°C (±0.008 %/°F)

Temperature coefficient is defined against the

potentiometer's full span.

Insulation resistance: ≥ 100 MΩ with 500 V DC

Dielectric strength:

2000 V AC @1 minute (control output 1 to control output 2

to position feedback 1 or position feedback 2 or internal bus

or internal power)

2000 V AC @1 minute (power input to FG; isolated on the

power supply module)

STANDARDS & APPROVALS

EU conformity:

EMC Directive

EMI EN 61000-6-4

EMS EN 61000-6-2

Low Voltage Directive

EN 61010-1, EN 61010-2-201

Measurement Category II (control output)

Pollution degree 2

Position feedback 1 or position feedback 2 to control

output 1 to control output 2: Reinforced insulation (300 V)

RoHS Directive

FUNCTIONS

• SSR (Solid State Relay)

SSR consists only of semiconductor elements, and thus SSR

is free from arc discharge and chattering which are typical

with electromagnetic relays.

SSR has excellent durability against vibration, physical

impact, and environmental influences.

• Zero-Cross Function

SSR with zero-cross function turns on when AC power

voltage is near zero.

When input is provided in the middle of a wave cycle, SSR

delays switching until the next time the voltage becomes

near zero, thus limiting transient switching noise voltage

and rush current.
