MODEL: R6D-PF1

R6D-PF1 SPECIFICATIONS

ES-7781-AK Rev.2 Page 3/4

https://www.m-system.co.jp/

EXTERNAL VIEW

(With the cover open)

Power LED

RUN LED

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm [inch]

5.9 (.23)

102 (4.02)

5

6

7

8

1

2

3

4

8–M3

EURO TERMINAL

WIRE INSERTION ANGLE: approx. 7°

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

Note: In order to improve EMC performance, bond the FG terminal to ground.

Caution: FG terminal is NOT a protective conductor terminal.

1

4

2

3

POWER LED

RUN LED

NC

NO

COM

5

6

7

8

FG

INTERNAL POWER

INTERNAL BUS

Ry

+

–

POWER INPUT

RUN CONTACT OUTPUT
