MODEL: R7F4DH
R7F4DH SPECIFICATIONS
ES-7799 Rev.7 Page 9/77
http://www.m-system.co.jp/
■ TERMINAL BLOCK CODE 4 (Tension Clamp)
115 (4.53)
123 (4.84)
DIN RAIL
35mm wide
4 (.16)
48 (1.89)
138 (5.43)
2 - 4.3 dia. 4 deep
(2 - 1.17 dia. 0.16 deep)
MOUNTING REQUIREMENTS unit: mm (inch)
125 (4.92)
