MICROCIRCUIT DATA SHEET

MRLM101A-X-RH REV 1B2

(Absolute Maximum Ratings)

(Note 1)

Supply Voltage

+22V

Differential Input Voltage

+30V

Input Voltage

(Note 3)

+15V

Ouput Short Circuit Duration

(Note 2)

Continuous

Operating Ambient Temp. Range

-55 C < Ta < +125 C

Maximum Junction Temperature

150 C

Power Dissipation at TA = 25 C

(Note 2)

750mW

H-Pkg (Still Air)

1200mW

H-Pkg (500LF/Min Air Flow)

1000mW

J-Pkg (Still Air)

1500MW

J-Pkg (500LF/Min Air Flow)

Thermal Resistance

ThetaJA

165 C/W

H-Pkg (Still Air)

89 C/W

H-Pkg (500LF/Min Air Flow)

128 C/W

J-Pkg (Still Air)

75 C/W

J-Pkg (500LF/Min Air Flow)

ThetaJC

39 C/W

H-Pkg

26 C/W

J-Pkg

Storage Temperature Range

-65 C <Ta< +150 C

Lead Temperature

300 C

(Soldering, 10 seconds)

ESD Tolerance

(Note 4)

3500V

Note 1:

Absolute Maximum Ratings indicate limits beyond which damage to the device may occur.

Operating Ratings indicate conditions for which the device is intended to be

functional, but do not guarantee specific performance limits. For guaranteed

specifications and test conditions, see the Electrical Characteristics. The

guaranteed specifications apply only for the test conditions listed. Some performance

characteristics may degrade when the device is not operated under the listed test

conditions.

Note 2:

The maximum power dissipation must be derated at elevated temperatures and is

dictated by Tjmax (maximum junction temperature), ThetaJA (package junction to

ambient thermal resistance), and TA (ambient temperature). The maximum allowable

power dissipation at any temperature is Pdmax = (Tjmax - TA)/ThetaJA or the number

given in the Absolute Maximum Ratings, whichever is lower.

Note 3:

For supply voltages less than +15V, the absolute maximum input voltage is equal to

the supply voltage.

Note 4:

Human body model, 100 pF discharged through 1.5k Ohms.

3
