CTSFW7040F-R22M Datasheet(PDF) 2 Page - Central Technologies

Part # CTSFW7040F-R22M
Description  Power Inductors - Shielded
PDF  2 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Manufacturer  CT [Central Technologies]
Direct Link  http://www.ctparts.com
Logo CT - Central Technologies

CTSFW7040F-R22M Datasheet(HTML) 2 Page - Central Technologies

  CTSFW7040F-R22M Datasheet HTML 1Page - Central Technologies CTSFW7040F-R22M Datasheet HTML 2Page - Central Technologies
Zoom Inzoom in Zoom Outzoom out
 2 / 2 page
background image
Manufacturer of Passive Components
800-684-5322 Inside US
949-453-1811 Outside US
Copyright © 2017 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
REV 10.09.17
Power Inductors - Shielded
www.ctparts.com
Typical Inductance vs Current Characteristics
Typical Temperature Rise vs Current Characteristics
R40
R22
R68
1R0
1R5
2R2
3R3
4R7
0.1
1
10
0.0
3.0
6.0
6.5
7.0
9.0
11.0
13.0
14.0
15.0
17.0
19.0
20.0
21.0
25.0
32.0
Current (A)
4R7
3R3
2R2
1R5
1R0
R68
R40
R22
0
5
10
15
20
25
30
35
40
0.0
3.0
6.0
6.5
7.0
9.0
11.0
13.0
14.0
15.0
17.0
19.0
20.0
21.0
Current (A)
CTSFW7040F Series
