2

N-Channel MOSFET Transistor

ISCNH060D

ELECTRICAL CHARACTERISTICS

SYMBOL

PARAMETER

CONDITIONS

MIN

TYP

MAX

UNIT

Drain-Source Breakdown Voltage

100

--

--

V

Gate Threshold Voltage

2

--

4

V

Drain-Source On-Resistance

--

--

6.0

mΩ

Gate-Body Leakage Current

--

--

±

0.1

uA

Zero Gate Voltage Drain Current

--

--

1

uA

Forward On-Voltage

--

--

1.2

V

NOTICE：

We reserves the rights to make changes of the content herein the datasheet at any time without

notification. The information contained herein is presented only as a guide for the applications of

our products.

Our products are intended for usage in general electronic equipment. The products are not

designed for use in equipment which require specialized quality and/or reliability, or in equipment

which could have applications in hazardous environments, aerospace industry, or medical

field. Please contact us if you intend our products to be used in these special applications.

We make no warranty or guarantee regarding the suitability of its products for any particular

purpose, nor does We assume any liability arising from the application or use of any products, and

specifically dWelaims any and all liability, including without limitation special, consequential or

incidental damages.
