AiT Semiconductor Inc.

www.ait-ic.com

Lo Rho F1210L

SMD PPTC RESETTABLE FUSE

REV1.0 - OCT 2017 RELEASED -

- 2 -

Typical Time-To-Trip at 23℃

A = F1210L175SL-06

B = F1210L200SL-06

C = F1210L260SL-06

D = F1210L300SL-06

E = F1210L350SL-06

F = F1210L380SL-06

G = F1210L400SL-06

H = F1210L450SL-06

I = F1210L650SL-06

J = F1210L700SL-06

K = F1210L750SL-06

Product Dimensions (Millimeters)

Part

Number

A

B

C

D

E

Min Max Min Max Min Max Min Max Min Max

F1210L175SL-06 3.00 3.43 2.35 2.80 0.30 0.70 0.25 0.75 0.10 0.45

F1210L200SL-06 3.00 3.43 2.35 2.80 0.30 0.70 0.25 0.75 0.10 0.45

F1210L260SL-06 3.00 3.43 2.35 2.80 0.30 0.70 0.25 0.75 0.10 0.45

F1210L300SL-06 3.00 3.43 2.35 2.80 0.30 1.00 0.25 0.75 0.10 0.45

F1210L350SL-06 3.00 3.43 2.35 2.80 0.30 1.00 0.25 0.75 0.10 0.45

F1210L380SL-06 3.00 3.43 2.35 2.80 0.60 1.00 0.25 0.75 0.10 0.45

F1210L400SL-06 3.00 3.43 2.35 2.80 0.60 1.00 0.25 0.75 0.10 0.45

F1210L450SL-06 3.00 3.43 2.35 2.80 0.60 1.00 0.25 0.75 0.10 0.45

F1210L650SL-06 3.00 3.43 2.35 2.80 0.60 1.00 0.25 0.75 0.10 0.45

F1210L700SL-06 3.00 3.43 2.35 2.80 0.60 1.00 0.25 0.75 0.10 0.45

F1210L750SL-06 3.00 3.43 2.35 2.80 0.60 1.00 0.25 0.75 0.10 0.45
