VM / MVM Series

Ceramic Housed Vertical Mount Resistor

Stackpole Electronics, Inc.

Resistive Product Solutions

Features:

•

Flameproof inorganic construction

•

High temperature potting compound

•

VM

– Wirewound element

•

MVM

– Metal oxide element for higher values

•

100% RoHS compliant and lead free without exemption

•

Halogen free

•

REACH compliant

VM:

MVM:

Electrical Specifications

Mechanical Specifications

0.276 ± 0.039

0.807 ± 0.039

0.433 ± 0.039

0.197 ± 0.039

0.031 ± 0.002

0.138 ± 0.020

inches

7.00 ± 1.00

20.50 ± 1.00

11.00 ± 1.00

5.00 ± 1.00

0.80 ± 0.05

3.50 ± 0.50

mm

0.335 ± 0.039

0.984 ± 0.039

0.492 ± 0.039

0.197 ± 0.039

0.031 ± 0.002

0.138 ± 0.020

inches

8.50 ± 1.00

25.00 ± 1.00

12.50 ± 1.00

5.00 ± 1.00

0.80 ± 0.05

3.50 ± 0.50

mm

0.374 ± 0.039

0.984 ± 0.039

0.512 ± 0.039

0.197 ± 0.039

0.031 ± 0.002

0.138 ± 0.020

inches

9.50 ± 1.00

25.00 ± 1.00

13.00 ± 1.00

5.00 ± 1.00

0.80 ± 0.05

3.50 ± 0.50

mm

0.374 ± 0.039

1.535 ± 0.059

0.512 ± 0.039

0.197 ± 0.039

0.031 ± 0.002

0.138 ± 0.020

inches

9.50 ± 1.00

39.00 ± 1.50

13.00 ± 1.00

5.00 ± 1.00

0.80 ± 0.05

3.50 ± 0.50

mm

0.472 ± 0.039

1.378 ± 0.039

0.630 ± 0.039

0.295 ± 0.039

0.031 ± 0.002

0.138 ± 0.020

inches

12.00 ± 1.00

35.00 ± 1.00

16.00 ± 1.00

7.50 ± 1.00

0.80 ± 0.05

3.50 ± 0.50

mm

VM10 / MVM10

Type / Code

C

D

Unit

VM2 / MVM2

VM7 / MVM7

VM3 / MVM3

VM5 / MVM5

A

B

Lead Diameter

Lead Length

5%

10%

VM2

2

250

VM3

3

300

VM5

5

350

VM7

7

500

VM10

10

700

MVM2

2

250

0.1 - 51K

-

MVM3

3

300

0.1 - 51K

-

MVM5

5

350

0.1 - 51K

-

MVM7

7

500

510 - 51K

-

MVM10

10

700

750 - 51K

-

Type / Code

Voltage Rating

(V)

TCR (ppm/°C)

Power Rating (W)

@ 70ºC

< 1 Ω = ± 800 ppm/ºC

> 1 Ω = ± 300 ppm/ºC

± 200 ppm/ºC

Maximum Working Voltage is limited by

unless specified otherwise.

0.56 - 680

Ohmic Range (

Ω) and Tolerance

0.056 - 100

0.1 - 100

0.1 - 100

0.39 - 470

√ P*R
