PPC-3150-RJ90

Dimensions

Unit: mm

I/O Appearance

Ordering Information

Part Number

Description

PPC-3150-RJ90A

Intel Celeron J1900 with 15" LED Panel, Res. T/S,

5 x RS-232, 1 x RS-232/422/485

PPC-3150-RJ90B

Intel Celeron J1900 with 15" LED Panel, Res. T/S,

5 x RS-232, 1 x RS-232/422/485

PS-DC19-65AE

Adapter AC100-240V 65W 19V 3.42A

PPC-WLAN-C1E

M.2 Wi-Fi Module with Antenna cable support 2T2R

1700008921

Power cord 3P/3P Power Supply 1.8M PSE

96CB-POWER-B-1.8MB Power code 3P CCC(China) 1.8M

PPC-174T-WL-MTE

Wall mount kit for PPC series

PPC-STAND-A1E

Stand For PPC Series (single acting hinge)

PPC-ARM-A03

PPC ARM VESA Standard

Note:

PPC-3150-RJ90Ax:Intel I211-AT/I210AT, 1GbE LAN chipset

PPC-3150-RJ90Bx:Realtek 8119i, 1GbE LAN chipset

Panel Cutout Dimensions: 381.00 x 302.00 mm

D E F

J K

A. 4 x RS-232 (optional by request)

B. 2 x RS-422/485 (optional by request)

C. 2 x RS-232 (optional by request)

D. 2 x RS-232

E. 1 x USB3.0

F. 3 x USB2.0

G. 2 x LAN

H. 3 x RS-232

I. 1 x RS-232/422/485

J. DC-In

K. Power button

75.0

379.4

392.3

284.0

69.2

25.5

7.5
