VLMS335.., VLMR335.., VLMK335.., VLMO335.., VLMY335..

www.vishay.com

Vishay Semiconductors

Rev. 1.2, 14-Sep-2022

6

Document Number: 84911

For technical questions, contact: LED@vishay.com

THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT

ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000

PACKAGE DIMENSIONS in millimeters

PACKING INFORMATION

PART

TAPE AND REEL

VLMx335xxxx-GS08

7500 (5 x 1500)

A

C

Ø2.4

Pin identification

3.5±0.2

3

+0.15

Mounting Pad Layout

4

1.2

1.6 (1.9)

0.8

Dimensions: Reflow and vapor phase (wave soldering)

Drawing-No.: 6.541-5067.02-4

specifications

according to DIN

Technical drawings

Issue: 5; 23.09.13

Dimensions in mm

Area covered

with solderresist
