19 / 60 page ![]() AD9511 Rev. A | Page 19 of 60 PIN CONFIGURATION AND FUNCTION DESCRIPTIONS PIN 1 INDICATOR 1 2 3 4 5 6 7 8 9 10 11 12 REFIN REFINB VS VCP CP VS CLK2 CLK2B VS CLK1 CLK1B FUNCTION VS OUT3 OUT3B VS VS OUT4 OUT4B VS VS OUT1 OUT1B VS 36 35 34 33 32 31 30 29 28 27 26 25 AD9511 TOP VIEW (Not to Scale) Figure 6. 48-Lead LFCSP Pin Configuration Note that the exposed paddle on this package is an electrical connection as well as a thermal enhancement. For the device to function properly, the paddle must be attached to ground, GND. |
|
