24 / 48 page

ams Datasheet

Page 23

[v1-00] 2016-Dec-30

Document Feedback

AS7261 − Detailed Descriptions

Figure 23:

FW Version Registers

Figure 24:

Control Setup Register

Addr: 0x02

FW_Version

Bit

Bit Name

Default

Access

Bit Description

7:6

Minor version

Minor version [1:0]

5:0

Sub version

Addr: 0x03

FW_Version

Bit

Bit Name

Default

Access

Bit Description

7:4

Major version

3:0

Minor version

Minor version [5:2]

Addr: 0x04/0x84

Control_Setup

Bit

Bit Name

Default

Access

Bit Description

7RST

R/W

Soft Reset, Set to 1 for soft reset, goes to 0

automatically after the reset

6INT

R/W

Enable interrupt pin output (INT),

1: Enable,

0: Disable

5:4

GAIN

R/W

Sensor Channel Gain Setting (all channels)

‘b00=1x; ‘b01=3.7x; ‘b10=16x; ‘b11=64x;

3:2

BANK

R/W

Data Conversion Type (continuous)

‘b00=Mode 0: X, Y, Z and NIR

‘b01=Mode 1: X, Y, D and C

‘b10=Mode 2: X, Y, Z, NIR, D and C

‘b11=Mode 3: One-Shot operation

1DATA_RDY0

R/W

1: Data Ready to Read, sets INT active if

interrupt is enabled.

Can be polled if not using INT.

RSVD

Reserved; Unused
