TC1303B

PRODUCT IDENTIFICATION SYSTEM

To order or obtain information, e.g., on pricing or delivery, refer to the factory or the listed sales office

.

Device:

TC1303B: PWM/LDO combo with Power-Good.

Options

Code

Code

Code

+50 mV

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

1

3.3V

3.2V

3.1V

3.0V

2.9V

2.8V

2.7V

2.6V

2.5V

2.4V

2.3V

2.2V

2.1V

2.0V

1.9V

1.8V

1.7V

1.6V

1.5V

1.4V

1.3V

1.2V

1.1V

1.0V

0.9V

Adjustable

1.375V

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

1

3.3V

3.2V

3.1V

3.0V

2.9V

2.8V

2.7V

2.6V

2.5V

2.4V

2.3V

2.2V

2.1V

2.0V

1.9V

1.8V

1.7V

1.6V

1.5V

0

1

2

3

Default

+50 mV to V1

+50 mV to V2

+50 mV to V1

and V2

* Contact Factory for Alternate Output Voltage and Reset

Voltage Configurations.

Temperature

Range:

E

=

-40°C to +85°C

Package:

MF

= Dual Flat, No Lead (3x3 mm body), 10-lead

UN

= Plastic Micro Small Outline (MSOP), 10-lead

(The MSOP package for this device has not been

qualified at the time of this publication. Contact your

Microchip sales office for availability.)

Tube or

Tape and Reel:

Blank

= Tube

TR

= Tape and Reel

Examples:

a)

TC1303B-IA0EMF:

2.5V, 3.3V, Default,

10LD DFN pkg.

b)

TC1303B-ZA0EUN:

Adj, 3.3V, Default,

10LD MSOP pkg.

c)

TC1303B-PG0EMFTR:

1.8V, 2.7V, Default,

10LD DFN pkg.

Tape and Reel
