ABSOLUTE MAXIMUM RATINGS

Table 4.

Parameter

Rating

Supply Voltage

±18 V

Input Voltage

−V ≤ VIN ≤ +V

Differential Input Voltage1

±1 V

Output Short-Circuit to GND

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Lead Temperature Range (Soldering 60 sec)

300°C

Junction Temperature

150°C

1

If the differential input voltage exceeds 1 V, limit the current to 5 mA.

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

θJA is specified with the device soldered on a circuit board with

its exposed paddle soldered to a pad (if applicable) on a 4-layer

JEDEC standard PCB with zero air flow.

Table 5.

Package Type

θJA

θJC

Unit

8-Lead LFCSP (CP-8-13)

78

20

°C/W

8-Lead SOIC (R-8) (AD8597)

140

39

°C/W

8-Lead SOIC (R-8) (AD8599)

120

36

°C/W

POWER SEQUENCING

Apply the op amp supplies simultaneously. The op amp supplies

must be stable before any input signals are applied. In any case,

the input current must be limited to 5 mA.
