CLX6F-RKB: PLCC6 3 IN 1 SMD LED

PRODUCT DESCRIPTION

These SMD LEDs are packaged in an

industry standard PLCC6 package. These

high reliability and high brightness LEDs

are designed to work in a wide range of

environmental condition and are ideally

suited for use in illumination applications.

Its wide viewing angle makes these LEDs

ideally suited for channel letter, or general

backlighting and illumination applications.

The flat top emitting surface makes it easy

for these LEDs to mate with light pipes.

FEATURES

• Size (mm): 3.5 x 3.4 x 2.8

• Dominant Wavelength:

Red (619 - 624nm)

• Luminous Intensity (mcd)

CLX6F-RKB:(2240-3550)

• Water-Resistant (IPX8)*

• Moisture Sensitivity Level: 5a

• Lead-Free

• RoHS Compliant

• Matte Surface

APPLICATIONS

• Architecture Lighting

• Channel Letter

• Backlight

*:This part is tested under the condition of assembling it on a PCB with isolating the electrical path by silicone.

The leads area of the LED is not IPx8 rated and it’s required to insulate for moisture by customer in outdoor

application.
