L2572
LINEAR INTEGRATED CIRCUIT
UNISONICTECHNOLOGIESCO.,LTD
11 of 14
www.unisonic.com.tw
QW-R102-032.A
-70
-60
-50
-40
-30
0.5
1.0
1.5
2.0
RF Input Level (dBm) Unmodulated
-20
-10
0
AGC Bias Resistor 5.1K
AGC Bias Current 297 A
AGC Load Resistor 3.9K
VCC = 5.0 V
Fig.5 AGC Output Voltage for Differing Values of AGC Bias Resistor
AGC Bias Resistor 10.5K
AGC Bias Current 150 A
AGC Load Resistor 4.7K
AGC Bias Resistor 32K
AGC Bias Current 52 A
AGC Load Resistor 10K
