WR-15 Probe Antenna

SAP-15-R2 is a a V-band probe antenna that operates from 50 GHz to

75 GHz. The antenna offers 6.5 dBi nominal gain and 115 degrees

typical half power beamwidth on the E-plane and 60 degrees typical half

power beamwidth on the H-plane. The antenna supports linear polarized

waveforms. The input of this antenna is a WR-15 waveguide with UG-

385/U anti-cocking flange.

Electrical Specifications:

Mechanical Specifications:

Parameter

Minimum

Typical

Maximum

Frequency

50 GHz

75 GHz

Gain

6.5 dBi

Polarization

Linear

3 dB Beamdwidth, E-Plane

115°

3 dB Beamdwidth, H-Plane

60°

Sidelobes, E-Plane

-10 dB

Sidelobes, H-Plane

-14 dB

Return Loss

9 dB

Specification Temperature

+25°C

Operating Temperature

-40°C

+85°C

Item

Specification

Antenna Port

WR-15 Waveguide with UG-385/U Anti-Cocking Flange

Size

1.50” (L) x 0.75 (Ø)

Material

Brass

Finish

Gold Plated

Weight

0.42 Oz

Outline

AP-RV-A

ECCN

EAR99

FEATURES

•

Rectangular Waveguide

Interface

•

Precisely Machined and Gold

Plated

•

Linear Polarization

• High Return Loss

APPLICATIONS

•

Antenna Ranges

•

Antenna Gain Measurements

• System Setups

SUPPLEMENTAL DETAILS
