11

11 - 3

Electrical Specifications III

TA = +25 °C, Vcc = 5V, Sci4 = Sci1 = 0V, Sci3 = Sci2 = 5V, Unless Otherwise Noted

Parameter

conditions

Min

typ.

Max

Units

Single-Ended Input Configuration

Input Network return Loss

up to 2.5 GHz

> 10

dB

Input resistance between IN+ and IN-

Between pins 3 and 4

120

Ω

Input Voltage range

VDIFFIN = VIN+ - VIN-

1.2

V

RMSOUT Output

output Voltage range

0.35 to 2.1

V

source/sink current compliance

rMsoUt held at Vcc/2

8 / -0.53

mA

Output Slew Rate (rise / fall)

sci4=sci3=sci2=sci1=0V, cofs=1nF

28 / 0.86

106 V/s

VSET Input (Negative Feedback Terminal)

Input Voltage range

For control applications with nominal

slope/intercept settings

0.35 to 2.1

V

Input resistance

5

MΩ

SCI1-4 Inputs, ENX Logic Input (Power Down Control)

Input High Voltage

0.7xVcc

V

Input Low Voltage

0.3xVcc

V

Input High current

1

μA

Input Low current

1

μA

Input capacitance

0.5

pf

Power Supply

supply Voltage

4.5

5

5.5

V

supply current with no input power

39

mA

supply current with -20 dBm

41.6

mA

standby Mode supply current

3

mA

HMC909LP4E

v02.0511

RMS POWER DETECTOR

SINGLE-ENDED, DC - 5.8 GHz
