ABSOLUTE MAXIMUM RATING

Symb ol

Parameter

Value

Uni t

VDS

Continuous Drain-Source Voltage (Tj = 25 to 125

oC)

-0.3 to 400

Maximum Current

I nternally Limited

VDD

Supply Voltage

0 t o 15

VOSC

Voltage Range Input

0 t o VDD

VCOMP

Voltage Range Input

0 to 5

ICOMP

Maximum Cont inuous Current

±2mA

Vesd

Electrostatic discharge (R = 1. 5 K

Ω C = 100pF)

4000

ID(AR)

Avalanche Drain-Source Current, Repetit ive or Not-Repet itive

(TC =100

o C, Pulse Width Limited by TJ max, δ <1%)

TBD

Ptot

Power Dissipation at T c = 25

oC60

Junct ion Operating Temperature

I nternally Limited

Tstg

St orage Temperature

-65 t o 150

THERMAL DATA

PENT AW ATT-HV

Po werSO-10(*)

Rthj-ca se

Thermal Resistance Junction-case

Max

1.9

oC/W

Rth j-a mb.

Thermal Resistance Ambient -case

Max

oC/W

(*) When mounted using the minimum recommended pad size on FR-4 board.

CURRENT AND VOLTAGE CONVENTIONS

13V

OSC

COMP SOURCE

DRAIN

VDD

VCOMP

VOSC

VDD

VDS

ICOMP

IOSC

IDD

FC00020

CONNECTION DIAGRAMS (Top View)

PENTAWATT HV

PENTAWATT HV (022Y)

PowerSO-10

VIPER50B/BSP

2/20
