Data Sheet
MAX74821
analog.com
Rev. 0
4 of 15
(VS = 5V, VCM = VS/2, TA = 25°C, unless otherwise noted.)
PARAMETER
SYMBOL
CONDITIONS
MIN TYP MAX
UNITS
Settling Time
tS
To 0.01%, 0V to 2V step
AV = +1
<1
µs
Unity Gain Bandwidth Product
GBP
10
MHz
Phase Margin
ΦM
65
Degrees
NOISE PERFORMANCE
Peak-to-Peak Noise
en p-p
f = 0.1Hz to 10Hz
2.3
µV p-p
Voltage Noise Density
en
f = 1kHz
9
nV/√Hz
f = 10kHz
7.3
nV/√Hz
Current Noise Density
in
f = 1kHz
10
fA/√Hz
