LS N114 datasheet(4/21 Pages) OSRAM

4 / 21 page

LG R971

4 Version 1.3 | 2021-09-28

Characteristics

F = 20 mA; TA = 25 °C

Parameter

Symbol

Values

Peak Wavelength

peak

typ.

572 nm

Dominant Wavelength 3)

dom

typ.

570 nm

Spectral Bandwidth at 50% I

rel,max

∆λ

typ.

30 nm

Viewing angle at 50% I

2φ

typ.

160 °

Forward Voltage 4)

F = 20 mA

typ.

max.

2.20 V

2.50 V

Reverse current 2)

R = 12 V

typ.

max.

0.02 µA

100 µA

Temperature Coefficient of Peak Wavelength

λpeak

typ.

0.1 nm / K

Temperature Coefficient of Dominant Wavelength

λdom

typ.

0.06 nm / K

Temperature Coefficient of Forward Voltage

typ.

-1.4 mV / K

Real thermal resistance junction/ambient 5)6)

thJA real

max.

800 K / W

Real thermal resistance junction/solderpoint 5)

thJS real

max.

450 K / W
