Figure 3. 8-Lead Lead Frame Chip Scale Package [LFCSP]

2 mm × 2 mm Body and 0.85 mm Package Height

(CP-8-30)

Dimensions shown in millimeters

ORDERING GUIDE

Model1, 2

Temperature Range

Package Description

Packing Quantity

Package Option

ADL8140ACPZN-CSL

−55°C to +125°C

8-Lead Lead Frame Chip Scale Package [LFCSP]

Tape, 1

CP-8-30

ADL8140ACPZN-R7-CSL

−55°C to +125°C

8-Lead Lead Frame Chip Scale Package [LFCSP]

Reel, 3000

CP-8-30

1 Z = RoHS Compliant Part.

2 The lead finish of the ADL8140ACPZN-CSL and ADL8140APCZN-R7-CSL is nickel palladium gold.
