83 / 192 page

DS12469 Rev 4

83/192

STM32L412xx

Electrical characteristics

163

6.3.5

Supply current characteristics

The current consumption is a function of several parameters and factors such as the

operating voltage, ambient temperature, I/O pin loading, device software configuration,

operating frequencies, I/O pin switching rate, program location in memory and executed

binary code.

The current consumption is measured as described in Figure 17: Current consumption

measurement scheme with and without external SMPS power supply.

Typical and maximum current consumption

The MCU is placed under the following conditions:

•

All I/O pins are in analog input mode

•

All peripherals are disabled except when explicitly mentioned

•

The Flash memory access time is adjusted with the minimum wait states number,

depending on the fHCLK frequency (refer to the table “Number of wait states according

to CPU clock (HCLK) frequency” available in the RM0394 reference manual).

•

When the peripherals are enabled fPCLK = fHCLK

The parameters given in Table 25 to Table 48 are derived from tests performed under

ambient temperature and supply voltage conditions summarized in Table 21: General

operating conditions.
