EFS

14/14

PACKAGE MECHANICAL DATA

Pentawatt HV with lead forming - TL5 (ASD

™)

REF.

DIMENSIONS

Millimeters

Inches

Min.

Typ.

Max.

Min.

Typ.

Max.

A

4.3

4.8

0.169

0.188

C

1.22

1.42

0.048

0.056

D

2.4

2.8

0.094

0.110

DIAM

3.65

3.85

0.144

0.152

E

0.35

0.45

0.014

0.018

F

0.65

0.75

0.026

0.030

G1

4.88

5.28

0.192

0.208

G2

7.42

7.82

0.292

0.308

H2

10.4

0.409

H3

10.05

10.4

0.396

0.409

L1

3.3

0.130

L2

14.24

14.64 0.560

0.576

L3

2.34

2.74

0.092

0.108

L5

2.6

3

0.102

0.118

L6

15.1

15.8

0.594

0.622

L7

6

6.6

0.236

0.260

R

0.5

0.020
