Document Number: 001-84932 Rev. *N

Page 124 of 139

PSoC® 5LP: CY8C58LP Family

Datasheet

Figure 11-82. IMO Frequency Variation vs. Temperature

Figure 11-83. IMO Frequency Variation vs. VCC

Tstart_imo Startup time[99]

From enable (during normal system operation)

–

µs

Jp-p

Jitter (peak to peak)[99]

F = 24 MHz

–0.9

–

F = 3 MHz

–1.6

–

Jperiod

Jitter (long term)[100]

F = 24 MHz

–0.9

–

F = 3 MHz

–12

–

Table 11-80. IMO AC Specifications (continued)

Parameter

Description

Conditions

Min

Typ

Max

Units

0.25

0.5

62.6 MHz

24 MHz

3 MHz

-0.5

-0.25

-40

-20

20406080

100

Temperature, °C

Notes

98. FIMO is measured after packaging, and thus accounts for substrate and die attach stresses.

99. Based on device characterization (Not production tested).

100.Based on device characterization (Not production tested). USBIO pins tied to ground (VSSD).
