5 / 24 page

AD8610/AD8620

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Supply Voltage

27.3 V

Input Voltage

VS− to VS+

Differential Input Voltage

± Supply Voltage

Output Short-Circuit Duration to GND

Indefinite

Storage Temperature Range

R, RM Packages

–65°C to +150°C

Operating Temperature Range

AD8610/AD8620

–40°C to +125°C

Junction Temperature Range

R, RM Packages

–65°C to +150°C

Lead Temperature Range (Soldering, 10 sec)

300°C

Rating

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

Table 4. Thermal Resistance

Package Type

θJA1

θJC

Unit

8-Lead MSOP (RM)

190

°C/W

8-Lead SOIC (R)

158

°C/W

1 θJA is specified for worst-case conditions; that is, θJA is specified for a device

soldered in circuit board for surface-mount packages.

ESD CAUTION

Rev. E | Page 5 of 24
