ST7SCR
82/101
CLOCK AND TIMING CHARACTERISTICS (Cont’d)
Figure 40. Typical Application with an External Clock Source
OSCIN
OSCOUT
fOSC
EXTERNAL
ST7XXX
CLOCK SOURCE
VOSCINL
VOSCINH
tr(OSCIN)
tf(OSCIN)
tw(OSCINH)
tw(OSCINL)
IL
90%
10%
