AS3722 datasheet(176/199 Pages) AMSOSRAM

176 / 199 page

ams Datasheet

Page 175

[v1-01] 2015-Sep-07

Document Feedback

AS3722 − Register Description

Figure 214:

Fuse11

Addr:abh

Fuse11

Bit

Bit Name

Default

Access

Bit Description

onkey_lpress_reset

Selects behavior on onkey_lpress

0 : change to power_off mode on long press

1 : apply reset on long press

6:5

onkey_shutdown_delay

Selects default state of the bit

on_shutdown_delay

4ac_ok_invert

Sets the polarity of the AC_OK pin

0 : High active for AC_OK

1 : Inverted: Low active for AC_OK

onkey_invert

Sets the polarity of the ONKEY pin

0 : High active for ONKEY

1 : Inverted: Low active for ONKEY

2SupResEn

0 : A reset is generated if VBAT or VSUP falls

below 2.5V. If VBAT falls below ResVoltFall

only an interrupt is generated (if enabled)

and the uProcessor can shut down the

system)

1 : A reset is generated if VBAT falls below

ResVoltFall or VSUP falls below vsup_min

gpio12_in_en

Don't use

0lid_invert

Sets the polarity of the LID pin

0 : High active for LID

1 : Inverted: Low active for LID
