AS7263 − Timing Characteristics

Figure 7:

AS7263 I²C Slave Timing Characteristics

Symbol

Parameter

Condition

Min

Typ

Max

Unit

I²C Interface

fSCLK

SCL clock frequency

400

kHz

tBUF

Bus free time

between a STOP and

START

1.3

μs

tHS:STA

Hold time

(Repeated) START

0.6

μs

tLOW

LOW period of SCL

clock

1.3

μs

tHIGH

HIGH period of SCL

clock

0.6

μs

tSU:STA

Setup time for a

repeated START

0.6

μs

tHS:DAT

Data hold time

0.9

μs

tSU:DAT

Data setup time

100

Rise time of both

SDA and SCL

300

Fall time of both SDA

and SCL

300

tSU:STO

Setup time for STOP

condition

0.6

μs

Capacitive load for

Each bus line

CB — total capacitance of

one bus line in pF

400

CI/O

I/O capacitance

(SDA, SCL)

Timing Characteristics
